Product Description
Double Sided PVC (White) is a white PVC film is coated on both sides with an aggressive solvent based modified acrylic adhesive. This tape is provided on a gold, siliconized paper release liner and wound on a 3” neutral core.
FEATURES/BENEFITS:
- Excellent temperature, UV, aging, and water vapor resistance.
- Bonds well to most materials, including difficult surfaces like foams, PE & PP films.
APPLICATIONS:
- Used for secure attachment of extruded plastic profiles in furniture and general industries.
- Used extensively for mounting of signs and large format graphics.
- Recommended for bonding trims in automotive and other industries.
PHYSICAL PROPERTIES:
|
Backing |
1.5mil White PVC Film |
|
|
Adhesive |
Modified Acrylic Adhesive |
|
|
Total Thickness (excludes liner) |
5.5 mils (0.140 mm) |
|
|
Liner |
90 g/m2 Gold Siliconized Release Paper |
|
|
Peel Adhesion |
|
|
|
|
– 1 minute dwell |
80 oz/inch |
|
|
– 20 minute dwell |
88 oz/inch |
|
|
– 24 hour dwell |
102 oz/inch |
|
Shear Resistance |
|
|
|
|
– Temperature at 73˚F |
> 400 hours |
|
|
– Temperature at 158˚F |
> 6 hours |
|
Application Temperature |
> 59˚F |
|
|
Temperature Resistance |
-40˚F to 158°F |
|
NOTE: The physical properties listed above are typical test results obtained from a series of laboratory tests and should not be used for the purpose of writing specifications. Before using this product, user shall determine the suitability of the product for his/her use; and user assumes all risks and liabilities in connection therewith. All test procedures used are in accordance with ASTM and PSTC methods.
Specifications
- Weight: 30 lb
